9/14
NOTE: At level 1 the folders will only display all the level 1 parameters. At level 2 the folders will only display all the
level 2 parameters.
IWP 760 LX Fan Condenser
PAR. DESCRIPTION
RANGE DEFAULT
LEVEL** U.M.
Link - Lin label
L00 Selects the instrument as Master (0), Slave (from 1
to 7)
0...4 0
2 num
L01 Number of Slaves in network (from 0 to 7).
Refers to Master only
0...4 0
2 num
L03 Refers to Master and Slave. Defrosting
Simultaneous/sequential.
Master: n=sequential; y = simultaneous
Slave: n=ignore; y=accept.
n/y n
2 flag
L04 Refers to Slave only. Distributed display.
n = slave displays local values;
y = slave displays Master display
n/y y
2 flag
L05 Activation of Master network functions:
n=does not ask slaves to activate remote functions;
y=asks slaves to activate slave remote functions:
n=ignores activation of remote functions from master;
y=accepts activation of remote functions from master
n/y n
2 flag
L06 Disables resources (compressors/fans, etc) at the
end of defrosting. n=does not disable; y=disables
n/y y
2 flag
L07 Alarm relay activated if slave alarm is generated
Refers to Master and Slave.
Master: n=does not activate alarm relay but displays
alarm folders; y= activates alarm relay
Slave: n=does not transmit the state of alarm to the Master
y= transmits the state of alarm to the Master
n/y y
2 flag
L08 Network functions enabled from Slave. Refers to
Slave and enables network functions AUX, light and
ON/OFF from button, function and D.I.
n/y y
2 flag
L09 Refers to slave only. Room probe shared Master
n/y n
2 flag
Communication
Add label
dEA (7) Device address in family
0...14
1
1
num
FAA (7) Device family
0...14
0
1 num
Pty Parity bit Modbus
n=none E=even o=odd
n/E/o
n
1 num
StP Stop bit Modbus
1b=0 2b=1
1b/2b
1b
1 flag
LOC Keyboard locked. Parameters can still be pro-
grammed.
n= keyboard not locked
y= keyboard locked
n/y
n
1 flag
PA1 Contains the password for level 1 parameters.
Enabled if not 0
0...250
0
1 num
PA2 Contains the password for level 2 parameters.
Enabled if not 0
0...250
0
2 num
ndt Display with decimal point.
n= without decimal point (only whole numbers)
y= with decimal point
n/y
n
1 flag
CA1 Temperature value to be added to that read by
probe 1 as specified by parameter CA
-12.0...12.0 0
1 °C/°F
CA2 Temperature value to be added to that read by
probe 2 as specified by parameter CA
-12.0...12.0 0
1 °C/°F
Display - diS label
Night & Day Control-
nAd label
E00 Functions enabled during events;
0=control disabled 1=reduced set point
2=reduced set point+light 3=reduced set point+light+aux
4=instrument off
0...4
0
2 num
E01 Hours/minutes of start of intervention. Starting
from this time, the “NIGHT” mode will be enabled.
The duration is determined by EO2
0...23/0...59
0
2 ore/min
E02 Duration of event. Sets the duration of the event
that begins at time E01 determined by value E00
0...99
0
2 ore
E03 (6) Blocking/unblocking daily or holidays defrosting.
0= “work days” defrost sequence defined by para-
meters dE1...dE8;
1= “festive/holidays” defrost sequence defined by
parameters F0...F8
0/1
0
2 flag
0 2
0 2
n 2
n 2
n 2
n 2
n 2
n 2
n 2
1
1
0 1
n 1
1b 1
n 1
0 1
1 2
n 1
0 1
0 1
- -
- -
- -
- -
CUSTOM SETTINGS
DEFAULT - LEVEL
