Elka ES 40 - Technical Data and Dimensions

© 1999 ELKA-Torantriebe GmbH & Co. Betriebs KG page ES 25, ES 30, ES 40
2
1. Technical data
ES 25 ES 25 HS ES 30 ES 40
Mains supply 230 V 50 Hz 230 V 50 Hz 230 V 50 Hz 230V 50 Hz
Drawn power 0.37 kW 0.37 kW 0.25 kW 0.26 kW
Max. current 2.5 amp 2.5 amp 2.5 amp 2.5 amp
Duty cycle 100% 100% 100% 100%
Running time ca. 1.4 s ca. 0.9 s ca. 2.3 s ca. 3.2 s
Maximum boom length 2,500 mm 2,500 mm 3,000 mm 4,000 mm
Effective length 2,280 mm 2,280 mm 2,780 mm 3,780 mm
Size (w x h x l) 350x1,100x300 mm 350x1,100x300 mm 350x1,100x300 mm 350x1,100x300 mm
Reversing on obstacle switchable switchable switchable switchable
Boom weight 4 kg 4 kg 4.7 kg 6 kg
Barrier weight 47.5 kg 47.5 kg 47.5 kg 50 kg
Foundation (on site) 550 x 500 mm 550 x 500 mm 550 x 500 mm 550 x 500 mm
Controller MO 62 MO 62 MO 62 MO 62
2. Dimensions
