This is only necessary if saved times are to be changed, or on replacement of the logic board. On delivery
5 seconds open before automatic closure and the running time for the barrier are already saved.
a) Open and close the barrier with the push buttons. This is to ensure that both limit switches are working.
Programming can only be carried out when the controller recognises both limit switches.
b) A time to stay open for automatic closure must be learned, but only takes effect when automatic closure
is activated. (Operating mode switch 4 on)
c) Push the learn button approx. 3 seconds - the red diagnostic LED starts flashing.
d) Push the learn button - the barrier opens and the time required is saved.
e) The diagnostic LED flashes at 1 second intervals. Push the learn button when the required time to stay
open has elapsed. The barrier closes and the appropriate open time and running time are saved.
f) The diagnostic LED lights for a short time to confirm saving data and the controller then switches to
operating status.
g) All information is saved in an EEPROM and is available after current failure.
