VRCGNDWS*C VRCGN8WS*1C LVRCGN8WS*1C
1000001741 (Rev. M - 09/18)
Page 5
Fig. 5
26
2
2
2
25
2
2
1
PUSH BUTTON MECHANISM
MECANISMO DE BARRA DE EMPUJE
MÉCANISME DU BOUTON-POUSSOIR
2
27
11
10
Fig. 6
22
16
21
21
4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Elkay EZH2O VRCGN8WS 1C Series and is the answer not in the manual?

Elkay EZH2O VRCGN8WS 1C Series Specifications

General IconGeneral
Product TypeOutdoor Fountain
MaterialStainless Steel
Bubbler ActivationPush Button
Bottle Filler ActivationPush Button
Rated For Outdoor UseYes
Freeze ResistantYes
Drain LocationBottom
ColorStainless Steel
MountingWall
FinishStainless Steel
ModelVRCGN8WS
