PAGE 1
4420DBBFFR_FTN LK 4420DBBFFR_FTN
98880C (Rev. C - 12/15)
INSTALLER
Owners Manual
4420 Bottle Filler Freeze Resistant Tubular Fountain & Pet Fountain
with 98837C Dual Valve Control Assembly
MODEL 4420BF1LDBFRMODEL 4420BF1UDBFR
4420DBBFFR Fountains are among the easiest to install Fountains on the market today. To assure
you install these models easily and correctly, PLEASE READ THESE SIMPLE INSTRUCTIONS
BEFORE STARTING THE INSTALLATION. CHECK YOUR INSTALLATION FOR COMPLIANCE
WITH PLUMBING, ELECTRICAL, AND OTHER APPLICABLE CODES. After installation, leave these
instructions with the Fountain for future reference.

Table of Contents

Questions and Answers

  • J
    Justin AndersonJul 29, 2025
    How to fix insufficient flow in Elkay Outdoor Fountain?
    • B
      Brandon MccoyJul 29, 2025
      If your Elkay Outdoor Fountain has insufficient flow, start by ensuring the shut-off valve is fully open. Also, verify that the supply pressure meets the minimum requirement of 20 PSI. If issues persist, clean the inlet strainer screen located within the valve body. Finally, inspect and clean the rubber orifice in the flow control, which is situated below the frost line in the bushing between the barb fitting and valve.
  • A
    Angela BarnettAug 7, 2025
    What to do if Elkay Outdoor Fountain has continuous flow?
    • L
      Lisa LewisAug 7, 2025
      If your Elkay Outdoor Fountain has continuous flow, first, make sure the push button isn't stuck or obstructed and springs back properly. Then, remove the four screws securing the plastic diaphragm block to the valve body and pull out the plastic and rubber diaphragm assembly. Check the tiny hole in the rubber diaphragm for any debris and clean it. Inspect the valve seat for grooves. If the valve seat is okay and the diaphragm hole was clear, check the rubber button at the center of the floating steel disc in the valve diaphragm block assembly. If it's worn, either turn the disc over or replace it. If the diaphragm and seats are in good condition, stretch the spring slightly. Finally, ensure the air bleed port on the valve plastic block assembly is not plugged.
  • C
    Clinton HolmesAug 18, 2025
    What to do if Elkay Outdoor Fountain has no flow?
    • M
      moranericaAug 18, 2025
      If your Elkay Outdoor Fountain has no flow, check the air tubing from the push button to the valve for leaks. Ensure the air tubing compression nut is hand tight. Disconnect the air tube from the push button, place your finger over the air outlet, and push the button to test the diaphragm. Tighten the diaphragm cap screws, and if necessary, replace the diaphragm.

Summary

Owners Manual

Installation Instructions

General Installation Tips

Guidance on general installation practices for the fountain unit.

Dual Valve Control Assembly Installation

Specific instructions for installing the 98837C or 98838C dual valve control assembly.

Site Preparation Detail

Rough-In for 4420 BF1 LDBFR

Rough-In for 4420 BF1 UDBFR

Trouble Shooting

Insufficient Flow Issues

Steps to resolve problems with low or reduced water flow from the fountain.

No Flow or Complete Blockage

Troubleshooting steps for when the fountain has no water flow at all.

Continued Flow Problems

Solutions for persistent or varied water flow issues after initial setup.

Continuous Unwanted Flow

How to fix issues where the fountain continues to flow unexpectedly.

Elkay EZH2O Series Specifications

General IconGeneral
ADA CompliantYes
Activation MethodPush Button
Rated for Outdoor UseYes
Bubbler MaterialStainless Steel
MaterialStainless Steel
Mounting TypeWall Mount
