Elkay LZ Series Installation, Care & Use Manual

Page 15 1000002119 (Rev. B- 06/15)
ENLZS8WS_1F
Error Graphics Board
Displayed Message
Alpha Board
Displayed
Message
LED
Board
Menu
Error Code
Display
Message Sent to Support Action (See Notes) Activation Automatic
Reset Yes/No
Notes
Evaporator Thermistor Open Circuit Maintenance Maintenance E001 SR Refrigeration Error - 001 -
6XSSRUW5HTXLUHG
Display Error - Shut Down Refrigeration - Send Error
Always On No ([WUHPHO\KLJKUHVLVWDQFHGHWHFWHG
Evaporator Thermistor Short Circuit Maintenance Maintenance E002 SR Refrigeration Error - 002 -
6XSSRUW5HTXLUHG
Display Error - Shut Down Refrigeration - Send Error
Always On No No resistance detected
Evaporator Thermistor Low Temperature (Variable) -See note Maintenance Maintenance E003 SR Refrigeration Low Temperature
Warning - 003 - Support 5HTXLUHG
Display Error - Shut Down Refrigeration - Send Error
Always On - See Note
No Variable set temp
Condenser Thermistor Open Circuit Maintenance Maintenance E004 Refrigeration Error - 004 -
6XSSRUW5HTXLUHG
Have fan turn on/off with compressor - Send Error
Always On No ([WUHPHO\KLJKUHVLVWDQFHGHWHFWHG
Condenser Thermistor Short Circuit Maintenance Maintenance E005 Refrigeration Error - 005 -
6XSSRUW5HTXLUHG
Have fan turn on/off with compressor - Send Error
Always On No No resistance detected
Condenser Over Temperature E006 Refrigeration Warning - 006
Send Error Always On Yes Variable set temp
Compressor Over Temperature Warning E007 Refrigeration Warning - 007 Send Error Can be turned off/
Not used in initial product launch
Yes Variable set temp
Compressor Over Temperature Error Maintenance Maintenance E008 SR Refrigeration Error - 008 -
6XSSRUW5HTXLUHG
Display Error - Shut Down Refrigeration - Send Error
Can be turned off/ Not used in initial product launch
No Variable set temp
Too many compressor cycles in a timeframe (Variable) E009 Refrigeration Error - 009 -
6XSSRUW5HTXLUHG
Send Error Always On No Variable set value
&RPSUHVVRUUXQVEXWHYDSRUDWRUWHPSHUDWXUHGRHVQRWGURSLQ¿UVW 30 seconds
Maintenance Maintenance E011 SR Refrigeration Error - 011 -
6XSSRUW5HTXLUHG
Display Error - Shut Down Refrigeration - Send Error
Always On No Use this for “Too many compressor
cycles in a timeframe (Variable)” too
Bottle Sensor Obstruction detected after 20 second timeout Please Clear
Bottle Filling Area
Please Clear Bottle Filling Area
Display Error
Always On Yes IR board must be present (Automatic
GHWHFWLRQYLD¿UPZDUH
Bottle Sensor Obstruction over “X” time Maintenance Maintenance E012
Bottle Filling Area Obstructed -012
Display Error - Send Error Always On Yes IR board must be present (Automatic
GHWHFWLRQYLD¿UPZDUH
Water Filter 80% Used Filter Status Solid
Yellow
Water Filter Over 80% Used Send Error (LED Status
Solid Red / Graphics Display status)
Filtered unit only Yes NFC and LED or Graphics Display
and NFC boards must both be present WRGHVLJQDWHWKHXQLWLVD¿OWHUHGXQLW $XWRPDWLFYLD¿UPZDUH
Water Filter 100% Used Filter Status Solid Red Please Change Water Filter Send Error (LED Status
Solid Red / Graphics Display status)
Filtered unit only Yes NFC and LED or Graphics Display
and NFC boards must both be present WRGHVLJQDWHWKHXQLWLVD¿OWHUHGXQLW $XWRPDWLFYLD¿UPZDUH
)LOWHUPLVVLQJIURPD¿OWHUHGXQLWRUQRQFRPSDWLEOH¿OWHU Maintenance Blinking
Red
E013 Filter Error -013 - No Filter or
Non-Compatible Filter
Display Error - Send Error (LED Status Blinking Red / Graphics Display status)
Filtered unit only Yes NFC board must be present. (Automatic
YLD¿UPZDUH
1)&%RDUGQRWGHWHFWHGRQD¿OWHUHGXQLW Maintenance Blinking
Red
E014 Filter Error - 014 - Filter
Board Not Detected
Display Error - Send Error
Filtered unit only Yes LED board be present to designate
WKHXQLWLVD¿OWHUHGXQLW$XWRPDWLF YLD¿UPZDUH
Note: Refrigeration Under Temperature Warning occurs when the evaporator temperature reaches or goes below the variable set temperature for more than 30 seconds. On the Alpha Display, Bottle count will display for 15 seconds with the “Maintenance” message displaying for 1 second.
Note: Refrigeration Under Temperature Warning occurs when the evaporator temperature reaches or goes below the variable set temperature for more than 30 seconds. On the Alpha Display, Bottle count will display for 15 seconds with the “Maintenance” message displaying for 1 second.
Troubleshooting Guide
