Connecting to and operating the system telephone at the pabx system (basic function including
DHCP)
Consult the installation instructions for the PABX system to determine which port can be used for connec
-
ting the IP-S400. Connect this port with the Ethernet PABX port on the system telephone.
•
Configure your PABX system for use with IP system telephones.
•
Define the MSNs for the IP system telephones within the PABX system.
•
Switch on the power (plug-in power supply unit) to the IP system telephone and wait until the tele
-
phone has been initialized.
OncetheIPsystem telephonehasbeeninitializedyou willberequestedtoselectthelanguageinthedisplay.
•
Select the display language.
Press the buttons to view the available langua
-
ges.
Which Country? }
Italiano
Español
Deutsch
®English
Française
Nederland
• Enter one of the MSNs that has been input to the PABX system (in the example shown here, 12) .
Confirm your entry by pressing
O
. Programm dial number
MSN-1>12
If no PIN has been entered in the system con-
figuration, press button
O
and button
O
again after being requested to do so.
IPS login PIN for sys
server
MSN-1>
• Swtich to Use DHCP.
Select »on«. Use automatic IP
adress setting
off
on®
•
The telephone and PABX system are synchronized.
If there is no connection to the PABX system (no LAN link, or the telephone has not been logged
in),thesymboll » -----/ /----‰ «willbeshowninthedisplayinsteadofthetime.
You can now use the IP system telephone at the ISDN or UP0 port.
Changing the label
Thelabels for the function keys are provided on the last page of this operating manual. Cut out the label you
wish to use.
To change the label panel, press the flexible cover together between your index finger and thumband lift it
out. The label panel can now be changed.
You can fill in the label panel via your PC yourself. The CD ROM supplied with the system contains an Ado
-
be Acrobat file with templates.
English
7
