Elmo 16-CL Optical - Wide-Angle Projection Lens F1.4 20 mm; Conversion Lens; Zoom Converter

!
• Wide-angle projection lens F1.4 20mm
•
Conversion lens
•
Zoom converter
This wide -angle lens is designed for
projection in a small room.
This attachment lens converts the
focal length
of the projection lens
to either xO.8 or x1.25, i.e., the
standard 50mm lens plus this
accessory serves as a 40mm wide-
angle lens or by reversing it a
63mm telep hoto lens. You can
make use of it when the projected
is too small or large .
When
this converter is used with
the projection lens, the focal
length
is converted cont in' uously
from xO .8 to x 1. 25. Using it ,
you can vary the size of the pro-
jected image wi thou t c ha nging th e
projector-to-screen distance.
PROJECTION DISTANCE AND IMAGE SIZE
