ELNA 664 - Replacing the Light Bulb; Cleaning the Feed Dog

76
1, 2, 3, 4
5, 6
1
2
3
4
5
1
2
3
1
2
3
4
5
1
2
3
Replacing the Light Bulb
1. Turn off the power switch and unplug the machine.
2. Remove the face plate setscrews, and remove the
face plate.
Face plate
Setscrews
To remove:
Push and twist to the left.
To attach:
Push and twist to the right.
Reattach the face plate, and tighten the face plate
setscrews.
Light bulb
To remove
To attach
Note:
* The machine is designed to use a 15 WATT
maximum light bulb.
* The light bulb will be HOT. Protect your fingers
when you handle it.
Cleaning the Feed Dog
1. Turn off the power switch and unplug the
machine.
2. Open the looper cover and side cover.
3. Remove the needles and presser foot.
4. Remove the needle plate set screw, and remove
the needle plate.
Needle plate
Needle plate set screw
5. Brush out the lint around the feed dogs to the
front by using the lint brush or use a vacuum
cleaner.
6. Reattach the needle plate, presser foot and
needles.
Close the looper cover and side cover.
Feed dogs
