6
Extra Wide Table
Use the extra wide table when the Embroidery hoop
RE20b, SQ20b or RE36b is attached to the machine.
Extract the 4 legs located the underside of the table.
Place the extra wide table on the machine.
q
Anti-slipping sticker (for Embroidery hoop RE36b)
Embroidery hoop RE36b unit includes the anti-slipping
sticker.
Peel and paste the sticker on the inner hoop of the
Embroidery hoop RE36b as shown to prevent slipping of
the ne fabrics.
q Anti-slipping sticker
w Inner hoop
NOTE:
Adjust the height of the extra wide table to the height
of the machine table by turning the adjusting screws
of 4 legs. Otherwise the carriage may hit the extra
wide table when attached. Use a Phillips screwdriver*
to turn the adjusting screw.
q Adjusting screw
* Phillips screwdriver is not included with the machine.
w
q
