User Manual: Windows I-Series Interactive Signage
UM600086 Rev A, Page 10 of 45
12V/24V Cash Drawer Power Switch
The user can switch the input power to the cash drawer with either 12V or 24V input.
RJ11 Cash Drawer Port
The cash drawer port is a RJ-11 connector and the default setting is set to +24V. The pinouts is
defined by the table below.
Pin # Signal Name Pin # Signal Name
1 GND 2 Channel1
3 DETECT 4 POWER
5 Channel 2 6 GND
