2-36 IntelliTouch/SecureTouch Guide
Optional Parts for Serial Connection
• External serial out cable
• DC to DC Power converter and cables.
• Controller power cable.
• Closed-cell Polyolefin foam with adhesive on one side.
• Service manual for the monitor.
• Internal mounting kit for serial controllers.
Optional Parts for USB Connection
• DC to DC Power converter and cables.
• Closed-cell Polyolefin foam with adhesive on one side.
• Service manual for the monitor.
• Internal mounting kit for controller.
• Controller power cable.
Notes on Disassembling the Monitor
Disassemble the display on a large, well-lit work surface. Leave space to set
aside major display components. Group screws and other hardware in small
containers or in specific areas on the work surface as you remove them, in
relation to the part of the display where you are working. If you complete the
installation process in one session (which may require several hours for your
first efforts), it is unlikely that you will have trouble reassembling the display.
Most display manufacturers connect the major components with detachable
cables that have labeled and keyed connectors; these cables are of lengths that
will usually connect to only one place. Also, screws are identifiable by type and
size, and usually will not fit in the wrong place. The most difficult problem with
missing or wrong hardware or connections will be with single ground cables
that attach to obscure ground points on the metal chassis. When in doubt, make
notes of the connection points.
