C-80 IntelliTouch/SecureTouch Guide
466907-000 Power Supply, U.S., Wall mount, 90-130 Vac, 60 Hz. in; +5, -12, +12 Vdc
out (also needs 323227-000 or 276875-000 power cord). Provides power
to the following obsolete controllers: 2300 serial in enclosure, 4002 seria
644845-000 Power Supply, International. Free standing, 115-230 Vac, 50/60 Hz. in;
+5, -12, +12 Vdc out (also needs 323227-000 or 276875-000 power cord).
Provides power to the following obsolete controllers: 2300 serial in
enclosure, 4002 serial enclosure, and Appl
655465-000 Power Converter, DC to DC, +8 to 30Vdc in, +5V regulated DC out. For
tapping monitor DC power for internal 2310B, 2500S or 2500U
controllers.
429761-000 Power cable, low voltage twisted pair for 2310B, 2500S or 2500U. 9 inch,
2X5F to 1X2F, 9M DC/DC
889507-000 Power cable, low voltage twisted pair for 2310B, 2500S and 2500U. 18
inch, 2x5F to flying leads.
816821-000 Power cable, low voltage twisted pair for E281-2310MX, 18 inch, 1x3F to
flying leads (non-standard)
323227-000 Power Cord - Europe. For use with a power supply (pcn 004100-215)
and/or monitors in Europe.
276875-000 Power Cord - United Kingdom. For use with a power supply (pcn
004100-215) and/or monitors in UK.
Cables
793054-000 USB connector cable, 18 inch length, to connect monitor to host computer
775252-000 USB connector cable, 72 inch length, to connect monitor to host computer
451043-000 Touchscreen cable for external controller, 72 in. DB9M to DB9F, goes
from back of monitor to controller
811847-000 Touchscreen cable for external controller, 108 in. DB9M to DB9F, goes
from back of monitor to controller
075795-000 Extension cable from controller, internal flat 8 in., 2x6M to DB9M, goes
from controller to back of monitor.
621717-000 Extension cable from controller, 48 in., 2x6 to DB9F, goes from
touchscreen controller to DB9F
304477-000 Extension cable from touchscreen cable, 48in., 2x6M to DB9M, goes
from touchscreen connector to back of monitor.
942741-000 Serial output cable, internal, ribbon 30 in., 2x5F to DB9F, goes from
controller to back of monitor.
454173-000 Serial output cable, external, 72 in. DB9M to DB9F. Goes from back of
monitor (with internal controller) to COM port.
459635-000 Ground lead with ring terminals, 17 in., Used to connect serial controller
or DB9 shell at back of display to chassis ground.
175175-000 Output cable for E281-2303. 72 in. 4-pin male mini-DIN to 4-pin male
mini-DIN.Goes from 002862-K1 or 002860-K1 to Macintosh ADB port.
084037-000 Macintosh serial cable for touchmonitors with internal serial controllers to
interface to Macintosh. DB9M to 8-pin mini-DIN male for Macintosh.
980773-000 Standard DIN keyboard power tap cable. E281-2310MX keyboard power
tap cable.
Part Number Description
