OSD Control Options
Control Description
Brightness Increases or decreases brightness.
Contrast Increases or decreases contrast.
H-Position Moves the screen left or right.
V-Position Moves the screen up or down.
Phase Increases or decreases the snow noise of the image after auto
adjustment is made.
Clock The dot clock is fine-adjusted after auto adjust.
Sharpness Adjusts sharpness of video.
OSD H-Position Moves the OSD position horizontally on the screen. When the
button is pressed, the OSD control menu will move to the right
side of the screen. Likewise, when the button is pressed, the
OSD control menu will move to the left side.
OSD V-Position Moves the OSD position vertically on the screen. When the
button is pressed, the OSD control menu will move to the top side
of the screen. Likewise, when the button is pressed, the OSD
control menu will move to the lower side.
OSD Time Adjusts the amount of the OSD menu is displayed.
Color Balance Press or to select 9300, 6500, 5500, 7500 and USER. Only when
selecting USER can you make adjustments to the R/G/B content.
Press Enter to restore to factory default setting.
Auto-Adjust Press Auto to enable this function. The Auto-Adjust will automatically
adjust V-Position, H-Position, Clock and Clock-Phase.
Recall Defaults Returns the monitor to its default settings.
OSD Language Select from English, French, German ,Spanish and Japanese.
Information Description Indicates the current resolution, H-Frequency and V-Frequency.
14 Elo Touchsystems 1915L User’s Guide
