Manual R1140-X0-ST-EN Release: 1.06 © Elotech GmbH Page 2/24
1. Contents
1.
Contents ...................................................................................................................................................... 2
2.
Type Code ................................................................................................................................................... 2
3.
Technical Data ............................................................................................................................................ 3
4.
R1140-10: Connection diagram .................................................................................................................. 4
5.
Display and Keyboard .................................................................................................................................. 6
6.
Operating Levels ......................................................................................................................................... 7
6.1
Configuration Level .............................................................................................................................. 8
6.2
Parameter Level ................................................................................................................................. 16
6.3
Operating Level .................................................................................................................................. 19
7.
CANopen, general ..................................................................................................................................... 21
8.
Profibus DP, general ................................................................................................................................. 21
9.
Error Displays ............................................................................................................................................ 22
10.
Installation Instructions .......................................................................................................................... 22
11.
Parameter Adjustments ......................................................................................................................... 23
Please read this operating manual carefully before starting up.
Observe the installation and connecting instructions.
Take care to the separat interface- and data transmission descriptions. See: www.elotech.de
Disclaimer of liability
We have checked the contents of the document for conformity with the hardware and software
described. Nevertheless, we are unable to preclude the possibility of deviations so that we are
unable to assume warranty for full compliance. The information given in the publication is,
however, reviewed regularly. Necessary amendments are incorporated in the following editions.
We would be pleased to receive any improvement proposals which you may have.
2. Type Code
R 1140 - 10 - 00 - x - x
1: Power supply: 230 VAC
2: Power supply: 115 VAC
3: Power supply: 24 VAC
5: Power supply: 24 VDC, +/-25%
2: Interface RS232-C Protocol: ELOTECH-Standard or „53“
4: Interface RS485 Protocol: ELOTECH-Standard or „53“
5: Interface 0/20mA Protocol: ELOTECH-Standard or „53“
7: CAN CANopen Device Profile DS-404
9: Profibus DP acc. to EN 50170
10: on-off-controller (2-point) or heating-off-cooling-controller (3-point)
OUT1: Relay and OUT4: bist. logic signal 0/18VDC
OUT2: Relay
OUT3: Relay
60: Continuous -controller (2/3-point)
OUT1: Relay
OUT2: Relay
OUT3: Relay
OUT4: continuous output signal 0/4...20mA
61: Continuous -controller (2/3-point)
OUT1: Relay
OUT2: Relay
OUT3: Relay
OUT4: continuous output signal 0/2...10V
