ELRO JGN - Operation modes

X101532E 10
4.5 Operation modes
Menu selection key / Function key
(1) Cooking
(2) –
(3) –
(4) –
(5) –
(A) Esc  Main menu
(B) Lifting/lowering device
*)
(C) WDS Water Dosing System
*)
(D) –
4.5.1 Setting and operating range
Operation mode
Settings
Setting and operating range
Started
Cooking
Temperature 30°C-Boiling point
Boiling 1-9
Pastamat
*)
Temperature 30°C-Boiling point
Boiling 1-9
4.5.2 Settings
Function
Settings
Description
Temperature
(2)(3)
Setting and operating range according to above table
Boiling
After 99°C switch over to boiling level
Levels 1-9 to adjust power level, e.g. „--7“ corresponds to a
power level of 77% of the appliance connected load
Time
Set time with (4)(5)
--:--:-- means continuous operation
Time smaller than 0 switch over to core temperature
*)
Timed start
Activate the delayed starting time with options (1)
Values can be changed by pressing the corresponding keys
(1) to (5)
