THURSDAY, 27 FEBRUARY 2014 PAGE 15 OF 31
EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
16. Use an appropriate drill bit to drill two holes to mount the motion sensor with two no. 4 self-tapping
screws (supplied) as shown below.
17. Use the two self-tapping screws to secure the motion sensor in position as shown below.
