8.0 Annex – UL information
Note: this annexe applies to 120VAC versions of the ems75vr only
Inputs:
Control input item
function
Input rating
Board ID terminals
Plug ID terminals
Main board
Input power supply
120VAC, 50/60Hz
1 A, 120 VA
J1 – J2
Live (L) – Neutral (N)
Mains socket – mains
plug
Compressor line input
120VAC
10 FLA 60LRA
J3
Compressor in
Compressor neutral input
---
---
Compressor ground
---
---
Light line input
120VAC, 2.1 A
250VA
J4
Lights in
Lights in
Not used
---
Control board
Evaporator switch
Class 2 limited energy
circuit less than 15 W
J21
Not used
Door switch
J22
Not used
Appliance sensor
J20
External 2-pin
connector
Aux/condenser sensor
J23
Not used
Communication:
Type
Ratings
Board ID terminal
Control board
Communication for external
display
Class 2 limited energy circuit less
than 15 W
J25
RJ45 LAN connection
J24
