EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
Outputs:
Output
designation
Type of load
Rating
Cycles of
cycle
Board ID
terminals
External ID
terminals
Main board
Compressor
relay
Compressor
motor
120VAC
10FLA 60LRA
100 K
J11
Compressor
out
Compressor
line / neutral
---
---
---
---
Heater/aux
relay
---
Not used
---
Not mounted
Not used
Light relay
Ballast
120VAC, 2.1 A
250VA
6 K
J5
Lights out
Lights out
---
Not used
---
---
Fan relay
---
Not used
---
Not mounted
Not used
8.1 Additional information
The purpose of this control is classified as an: Operational Control.
The type on construction is: Integrated Control.
Maximum ambient operating temperature
0˚C up to 35˚C (32˚F up to 95˚F)
Overvoltage category
III – or better
Pollution degree
2 or better
Software class
A
Type 1 action
Rated impulse voltage
2500V
Elstat UL approvals:
UL 60730-1
CSA E 60730-1
UL 60730-2-9
CSA E 60730-2-9
UL reference : E325501
