4.0 Mount the appliance sensor
4.1 Appliance sensor installation
The appliance sensor is placed in front of the evaporator and is secured into position using the holder, which is
a small hook with a magnetic base.
4.2 How to mount the appliance sensor
Mount the appliance sensor as follows:
18. Identify the access cover that allows cable to be passed between the compressor and refrigeration
compartments.
19. Remove the screw from one side of the cover and loosen the screw on the other side as shown below.
