Connection
06
Power cord (AC)
Be sure to connect the power cord to an AC outlet
which supplies the correct voltage.
Hold the power plug when plugging or unplugging the
power cord.
PRE OUT ( SUB WOOFER ) jack
Use this jack to connect a powered sub-woofer or
passive sub-woofer with a power amplifier (OPTIONAL) .
AC OUTLETS (SWITCHED)
These outlets are only active when the receiver is
turned on.
Caution:
Make sure that the total power consumption of all
equipment connected to the outlets on the receiver does
not exceed 100 watts.
(OPTIONAL)
POWERED
SUBWOOFER
SURROUND
BACK
SURROUND SURROUND
SPEAKERS, PRE OUT, AC OUTLETS
