Page #6 background imageLoading...
Page #6 background image
Rectifier
PSR327
User Manual
Page 6 (20)
©2009. ELTEK VALERE DEUTSCHLAND GmbH. UM_PSR327_21TE_ E_R5.0
2. General Information
The PSR327 rectifier rectifies sinusoidal AC input voltage to DC output voltage.
The PSR327 is a hot plug-in module with rear side connectors and is designed to be mounted in an
assembly set 19’’ sub rack (see section 3.2). Due to the state-of-the-art circuitry design, the unit has
very low losses and therefore very compact dimensions, low weight and high power density.
The PSR327 rectifier can be used in all DC applications with or without battery.
The rectifier is delivered with factory set default values for lead acid batteries. If the rectifier is to be
used for NiCd batteries, the default values must be parameterized accordingly using a CAN dongle and
special software.
The nominal output power per unit is 2700 W. Up to a maximum of 48 modules can be switched in
parallel to increase the system output power or to build redundant power supply systems (n + 1-
principle).
3. Type Range/Equipment
Type Designation Material Code Nominal Output Voltage Nominal Output Current
PSR327/48-56 101-027-158.00 48VDC 56ADC
PSR327/60-45 101-027-168.00 60VDC 45ADC
PSR327/110-25 101-027-178.00 108VDC 25ADC
PSR327/220-12.5 101-027-188.00 216VDC 12.5ADC
3.1 Main Data
Nominal input voltage: 230V
AC
Nominal input current: 12.9A
AC
Input frequency: 47- 63Hz
Nominal output power 2700W
For more specific data, see section 8.
