•nomountingnexttoawindow
•greatestpossibledistancetometalobjectstoavoidany
unnecessary reduction of the operating range
b) Mounting the wall holder
Proceed as follows to mount the wall
holder:
•Remove the wall holder on the
back of the heating
control, slide it down for this.
• Place the wall holder vertically
against the wall
with the round side pointing up
(see picture).
•Mark the positions of the bores
through the two slotted holes.
•Dependingonthetypeofwalldrilltwo6mmholesand
insert suitable dowels.
When drilling the bores and tightening the screws
make sure not to damage any power lines or gas
or water pipes, etc.!
•Fixthewallholderusinge.g.theenclosedscrews.Payat-
tention that the two recessed slotted holes for the screws
point in your direction.
•Ifnotalreadydoneso,insertthebatteriesintotheheating
control before you slide the heating control on the wall holder.
•Slidingoftheheatingcontrolonthewallholderisnow
possible from the top.
