EMAK efco ZEPHYR 72 User Manual

GB
34
Key to functional wiring diagram (Fig.25)
Q0 = ignition key switch:
- pos.0 = machine off (pos. OFF)
- pos.1 = machine in reverse with mowing (pos. R)
- pos.2 = machine forward with mowing (pos. 1)
- pos.3 = on (pos. ON)
Q1 = PTO clutch control switch (13 H)
Q1.1 = 1.2 W blade engaged indicator lamp (13 H)
H1 = Error warning light (13 H)
S1 = Machine stopped and travelling microswitch (NC)
S2 = grass-catcher opening micro-switch (NC)
S3 = seat micro-switch (NO)
S4 = parking brake micro-switch (NO)
S6 = grass-catcher full micro-switch (NC)
S7 = machine stopped and reverse gear micro-switch (NC)
S.E. = electronic circuit board
EF = PTO clutch (13 H)
X.101.S = Engine connector
F1 = Electrical system main fuse (5A)
F2 = Engine main fuse (15A)
F3 = Alternator main fuse (100 A)
X114 = circuit board power supply connector
K108 = starting relay
K115.1 = Engine stop relay
K115.2 = Start enable relay
X118 = PTO clutch connector (13 H)
M120 = starter motor
MCI = internal combustion engine
G110 = Battery
A = Engine stop
B = Alternator
Cable colour coding
A = light blue G = yellow M = brown S = pink
B = white H = grey N = black V = green
C = orange L = blue R = red
Electrical system 12 V
Battery 17 Ah
Front tyres 11” x 4”-4
Rear tyres 15” x 6”-6
Front tyre pressure 1,5 bar
Rear tyre pressure 1,0 bar
Overall dry weight 192 kg
Inside turning circle 0,9 m
Cutting height 3÷8 cm
Cutting width 72 cm
Grass-catcher capacity 180 litres
Ground speed (at 3000 min
-1
):
- in forward drive 0÷8,6 km/h
- in reverse drive 0÷3,2 km/h
Sound pressure level
(LpA EN ISO 5395-1 - EN ISO 5395-3)
90,5 dB (A)
Uncertainty 2,0 dB (A)
Measured sound power level
(LwA 2000/14/EC - EN ISO 3744 -
EN ISO 5395-1 - EN ISO 5395-3)
98,8 dB (A)
Uncertainty 1,2 dB (A)
Guaranteed sound power level
(LwA 2000/14/EC - EN ISO 3744 -
EN ISO 5395-1 - EN ISO 5395-3)
100,0 dB (A)
Vibration level (EN ISO 5395-1 -
EN ISO 5395-3) steering wheel
3,0(sx)-3,4(dx) m/s
2
Uncertainty (EN 12096) 1,1 m/s
2
Vibration level
(EN ISO 5395-1 - EN ISO 5395-3) seat
0,47 m/s
2
Uncertainty (EN 12096) 0,23 m/s
2
Overall dimensions 198x73x110 cm
10. TECHNICAL DATA
