two positions:
«A» = Brake off
«B» = Brake engaged
– The brake is engaged by pressing the pedal (4.3) right down and moving the
lever to position «B». When you take your foot off the pedal it will be blocked
by the lever in the down position.
– To disengage the parking brake, press the pedal (4.3). The lever will return to
position «A».
4.4 S
PEED CHANGE LEVER
This lever has five positions for the three forward gears, the neutral position «N»,
and reverse «R».
– To change gear, press the pedal (4.3) halfway down and move the lever as per
the indications on the label.
Reverse must be engaged when the machine has
stopped.
4.5 C
UTTING HEIGHT ADJUSTING LEVER
There are five positions for this lever, shown as «1» to «5» on the plate, which
correspond to various cutting heights from 3 to 7.5 cm.
– To go from one position to another, move the lever sideways and put it back in
one of the stop notches.
4.6 L
EVER ENGAGEMENT AND BRAKE OF BLADE
The lever has two positions, as shown on the plate:
«A» = Blade disengaged
«B» = Blade engaged
– If the blade is engaged when safety conditions have not been complied with,
the engine shuts down and cannot be restarted (☛ 5.2).
– In disengaging the blade (Pos. «A»), a brake is simultaneously activated which
stops their rotation within a few seconds.
!
WARNING!
EN 12 CONTROLS AND INSTRUMENTS
