Emax Interceptor RaceView User Manual

Tinyhawk II
1
emax-usa.com
Product specification
Product list
1. Tinyhawk II × 1
2. Instruction manual × 1
3. Emax 1s HV 450 mAh × 1
4. Emax 2s HV 300 mAh × 1
5. Charger × 1
6. Extra Propeller Set (2x CW, 2x CCW)
7. Screwdriver x 1
8. Spare screws x 1
9. fc damper x 1
10. rubberbands x 1
Tinyhawk II
Parameter
Diagonal wheelbase (without paddles)
75mm
Maximum size of the aircraft (without
antenna, cable tie)
110×96×42(mm)
Aircraft weight (without battery)
31g
Motor
TH0802 16000KV
Propeller
Avan TH Turtlemode Propeller
Main Flight Controller
F4（MATEKF411RX firmware）
4 in one 5A ESC
SPI RX receiver（Compatible with Frsky remote
control D8/D16 mode
）
Camera
RunCam Nano 2 Camera
Transmitter
0-25-100-200mW Adjustable frequency 37CH,
Support SmartAudio
LED
Red
Battery
1 Cell 450 mAh HV lipo battery

Emax Interceptor RaceView Specifications

General

Brand	Emax
Model	Interceptor RaceView
Category	Drones
Language	English
