Embrace™ Nest Operation Manual (0602-50001-002) Page 37
TECHNICAL SPECIFICATIONS
ACCUTEMP™ HEATER
Operating Voltage: 230 V AC, 50 Hz
Fuse Rating: 3.15 A Time-lag/ Slow Blow fuse
Power Consumption: 500 Watt (peak power consumption at 230 V, approx. 15 Watt power
consumption in dwell mode)
Dimensions: 440 mm x 290 mm x 70 mm
Weight: 2.5 Kg
Heat-up time:
May vary depending on ambient temperature, and supply voltage. On an average, the heat up time
is approximately 35 minutes under 230 V AC input and 25 °C ambient operating temperature.
Table 1: Performance at varying ambient temperatures
Time taken to heat WarmPak™ to
ready state in AccuTemp™ Heater
WarmPak™ duration in OK range
10 °C approximately 35 minutes ~1.5 hours
25 °C approximately 35 minutes at least 4 hours
34 °C approximately 25 minutes over 10 hours
Low Voltages may take longer.
Heating Element:
Heating element has been designed to withstand up to 1.5 kV breakdown voltage.
Aluminum plate has been grounded, and connected to the ground pin of the power cord
Operating Conditions:
Temperature: 10 to 34°C
Humidity: 30 to 75%
Shipping and Storage Conditions:
Temperature: -20 to 40°C
Humidity: 10 to 90% (non condensing)
WARMPAK™
Dimensions: 380 mm x 220 mm
Weight: 1.3 kg
Operating Conditions:
Temperature: 10 to 34°C
Humidity: 30 to 75%
