Emec VMS MF - Discharge Hose; Discharge Hose Connection

12
Discharge hose.
Insert one side of discharge hose into discharge connector as shown in fig (C).
Insert other side of discharge hose into product’s tank.
During priming procedure product exceeding will flow into tank.
For priming procedure see page 14.
fig (C)
Discharge hose
Discharge Knob
To Delivery hose
To Suction hose
