Note
Figure 3-1 depicts the terminal block of legacy Gateways prior to the
introduction of PoE capabilities. Figure 3-2 shows the terminal block
arrangement of a PoE version of the Gateway. If the Gateway will be
powered via the standard 24 volt power input terminals, and no PSE is
desired, it is not necessary to change the default settings of the PoE jumper
matrix.
Note
The Gateway enclosure case should always grounded in accordance with
national and local electrical codes. The most effective grounding method is a
direct connection to earth ground with minimal impedance.
Quick Start Guide September 2020
6 Emerson.com/Rosemount
