* Please refer to the appropriate Solutions Module manual.
56 Trip before Pr 55
Pr 10.21
57 Trip before Pr 56 Pr 10.22
58 Trip before Pr 57 Pr 10.23
59 PLC ladder program enable 0 Pr 11.47
60 PLC ladder program status
Pr 11.48
61 Configurable parameter 1
62 Configurable parameter 2
63 Configurable parameter 3
64 Configurable parameter 4
65 Configurable parameter 5
66 Configurable parameter 6
67 Configurable parameter 7
68 Configurable parameter 8
69 Configurable parameter 9
70 Configurable parameter 10
71 Pr 61 set up parameter Pr 11.01
72 Pr 62 set up parameter
Pr 11.02
73 Pr 63 set up parameter
Pr 11.03
74 Pr 64 set up parameter
Pr 11.04
75 Pr 65 set up parameter
Pr 11.05
76 Pr 66 set up parameter
Pr 11.06
77 Pr 67 set up parameter
Pr 11.07
78 Pr 68 set up parameter
Pr 11.08
79 Pr 69 set up parameter
Pr 11.09
80 Pr 70 set up parameter
Pr 11.10
81 Frequency reference selected
Read only diagnostic parameters
Pr 1.01
82 Pre-ramp reference Pr 1.03
83 Post-ramp reference Pr 2.01
84 DC Bus voltage Pr 5.05
85 Motor frequency Pr 5.14
86 Motor voltage Pr 5.02
87 Motor speed Pr 5.04
88 Motor current Pr 4.01
89 Motor active current Pr 4.02
90 Digital I/O read word Pr 8.20
91 Reference enabled indicator Pr 1.11
92 Reverse selected indicator Pr 1.12
93 Jog selected indicator Pr 1.13
94 Analog input 1 level Pr 7.01
95 Analog input 2 level Pr 7.02
Par Description
Default
Corresponding extended
menu parameter
Setting
Eur USA
