2-17
Installation
Table 2-8. Flanged-Style Flowmeter (4-through 12-in./ 100 through 300mm Line Sizes) (Refer to Figure 2-11)
Nominal Size
Inch (mm)
Flange
Rating
Face-to-face A
Inch (mm)
(1)
A ANSI RTJ
Inch (mm)
Diameter B
Inch (mm)
(2)
C
Inch (mm)
(3)
Weight
(4)
lb (kg)
4 (100) Class 150
Class 300
Class 600
Class 900
10.3 (262)
11.0 (279)
12.8 (325)
13.8 (351)
10.8 (274)
11.6 (295)
12.9 (328)
13.9 (353)
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
9.6 (244)
9.6 (244)
9.6 (244)
9.6 (244)
50.7 (23,0)
70.8 (32,1)
96.5 (43,8)
119.7 (54,3)
PN 16
PN 40
PN 64
PN 100
PN 160
8.4 (213)
9.4 (239)
10.4 (264)
11.3 (287)
12.1 (307)
–
–
–
–
–
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
9.6 (244)
9.6 (244)
9.6 (244)
9.6 (244)
9.6 (244)
40.1 (18,2)
49.2 (22,3)
62.1 (28,2)
78.5 (35,6)
85.8 (38,9)
JIS 10K
JIS 20K
JIS 40K
8.7 (220)
8.7 (220)
11.8 (300)
–
–
–
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
9.6 (244)
9.6 (244)
9.6 (244)
37.0 (16,8)
44.9 (20,4)
75.3 (34,2)
6 (150) Class 150
Class 300
Class 600
11.6 (295)
12.4 (315)
14.3 (363)
12.1 (307)
13.0 (330)
14.5 (368)
5.7 (144,8)
5.7 (144,8)
5.7 (144,8)
10.8 (274)
10.8 (274)
10.8 (274)
90.0 (40,8)
129.5 (58,7)
195.5 (88,7)
PN 16
PN 40
PN 64
PN 100
8.9 (226)
10.5 (267)
12.1 (307)
13.7 (348)
–
–
–
–
5.7 (144,8)
5.7 (144,8)
5.7 (144,8)
5.7 (144,8)
10.8 (274)
10.8 (274)
10.8 (274)
10.8 (274)
75.6 (34,3)
95.3 (43,2)
138.8 (63,0)
168.5 (76,4)
JIS 10K
JIS 20K
JIS 40K
10.6 (270)
10.6 (270)
14.2 (360)
–
–
–
5.7 (144,8)
5.7 (144,8)
5.7 (144,8)
10.8 (274)
10.8 (274)
10.8 (274)
79.8 (36,2)
97.7 (44,3)
175.9 (79,8)
8 (200) Class 150
Class 300
Class 600
13.6 (345)
14.3 (363)
16.6 (422)
14.1 (358)
15.0 (381)
16.7 (424)
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
11.7 (297)
11.7 (297)
11.7 (297)
139.6 (63,3)
196.2 (89,0)
295.0 (133,8)
PN 10
PN 16
PN 25
PN 40
PN 64
PN 100
10.5 (266)
10.5 (266)
11.9 (302)
12.5 (318)
14.2 (361)
15.8 (401)
–
–
–
–
–
–
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
11.7 (297)
11.7 (297)
11.7 (297)
11.7 (297)
11.7 (297)
11.7 (297)
109.6 (49,7)
108.5 (49,2)
136.3 (61,8)
154.8 (70,2)
214.6 (97,3)
279.9 (127)
JIS 10K
JIS 20K
JIS 40K
12.2 (310)
12.2 (310)
16.5 (420)
–
–
–
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
11.7 (297)
11.7 (297)
11.7 (297)
109.9 (49,9)
134.3 (60,9)
255.7 (116)
10 (250) Class 150
Class 300
Class 600
14.6 (371)
15.8 (401)
19.1 (485)
15.1 (384)
16.4 (417)
19.2 (488)
9.56 (243)
9.56 (243)
9.56 (243)
12.8 (325)
12.8 (325)
12.8 (325)
197.2 (89)
285.2 (129)
475.3 (216)
PN 10
PN 16
PN 25
PN 40
PN 64
PN 100
11.9 (302)
12.1 (307)
13.5 (343)
14.8 (376)
16.4 (417)
18.9 (480)
–
–
–
–
–
–
9.56 (243)
9.56 (243)
9.56 (243)
9.56 (243)
9.56 (243)
9.56 (243)
12.8 (325)
12.8 (325)
12.8 (325)
12.8 (325)
12.8 (325)
12.8 (325)
156.3 (71)
161.1 (73)
197.4 (90)
245.3 (111)
306.3 (139)
443.0 (201)
JIS 10K
JIS 20K
JIS 40K
14.6 (371)
14.6 (371)
18.1 (460)
–
–
–
9.56 (243)
9.56 (243)
9.56 (243)
12.8 (325)
12.8 (325)
12.8 (325)
173.3 (79)
220.5 (100)
377.3 (171)
12 (300) Class 150
Class 300
Class 600
16.8 (427)
18.0 (457)
20.5 (521)
17.3 (439)
18.7 (475)
20.7 (526)
11.38 (289)
11.38 (289)
11.38 (289)
13.7 (348)
13.7 (348)
13.7 (348)
296.0 (134)
413.2 (187)
592.2 (269)
PN 10
PN 16
PN 25
PN 40
PN 64
PN 100
13.2 (335)
13.9 (353)
15.0 (381)
16.9 (429)
18.8 (478)
21.2 (538)
–
–
–
–
–
–
11.38 (289)
11.38 (289)
11.38 (289)
11.38 (289)
11.38 (289)
11.38 (289)
13.7 (348)
13.7 (348)
13.7 (348)
13.7 (348)
13.7 (348)
13.7 (348)
203.1 (92)
223.4 (101)
267.8 (121)
345.7 (157)
428.5 (194)
640.8 (291)
JIS 10K
JIS 20K
JIS 40K
15.7 (399)
15.7 (399)
19.7 (500)
–
–
–
11.38 (289)
11.38 (289)
11.38 (289)
13.7 (348)
13.7 (348)
13.7 (348)
224.5 (102)
287.1 (130)
504.7 (229)
(1) ±0.14 inch (3.6 mm)
(2) ±0.03 inch (0.8 mm)
(3) ±0.20 inch (5.1 mm)
(4) Add 0.2 lb (0,1 kg) for display option.
