Emerson 8800A - Page 31

2-21
Installation
Figure 2-15. Vortex Dual-Sensor Style Flowmeter Dimensional Drawings (10-through 12-in./250 through 300 mm Line Sizes)
2.00
(51)
2.00
(51)
A
Electrical Connection ASME
B16.5 (ANSI)
1
/2-14 NPT (2 places)
C
C
Diameter B
1.00 (25)
Terminal Cover
3
.
20
(81)
NOTE
Dimensions are in inches (millimeters)
1.10
(28)
2.85
(72)
2.56
(65)
3.06
(78)
Display Options
8800-8800c_01, 8800c_02
