NOTE
Do not pull the adaptor more than 1.5 inches (40 mm) from the top of
the support tube. Damage to the sensor may occur if the sensor cable is
stressed.
Figure 4-16. Coaxial Cable Connections
½ NPT Optional Conduit Adapter or
Cable Gland (Supplied by Customer)
Coaxial Cable
Meter Adapter
Union
Washer
Sensor Connection
Access Cover
Support Tube
Access Cover Screw
Meter Body
Nut
8800-0470A02C
