Procedure
1. If the equipment surface has a radius of curvature that is less than 4 in. (100 mm),
grind a flat surface approximately 0.5 in. (12.7 mm) in diameter.
2. Using a wire brush and plant-approved cleaner, clean and degrease the surface
area.
3. Using a two-part epoxy (such as Emerson P/N A92106)), spray the activator onto
the mounting surface. Place a light coat of epoxy on the surface of the mounting
pad and hold firmly against the machine spot face surface for one minute.
Note
If the adhesive does not set within 1 minute, it indicates that too much epoxy is
applied or that the mounting surface is not prepared properly. Repeat steps 2–3.
4. Ensure that the mounting pad / base of the device is grounded to the machine case.
Use a two-part conductive epoxy (such as Loctite Ablestik 2902) and make a bead
that bridges the mounting pad to the machine case.
5. Use a multimeter to check conductivity between the mounting pad and machine
surface.
3.3.3
Triaxial quick connection
Use this mount in scenarios where there is a need to remove the monitor from the
machine but you also need a more permanent type of installation. This mounting
mechanism has two components: the receptacle that attaches to the device and the base
that attaches to the machine. The base itself comes in two options: epoxy mounted, or
stud mounted.
Procedure
1. Find the right location for the base. Make sure that the base notch is oriented with
either the X or the Y axis of the device.
2. Install the device on the receptacle and orientate the whole assembly together.
3. Install the base on the machine using either Stud mounting (preferred) or Epoxy
mounting (alternative).
4. Align the notch on the receptacle with the notch on the base and give it a ¼ turn. It
will lock in the same place every single time.
3.3.4
Motor fin mounting
Procedure
1. Prepare cooling fins on motor for mounting by scraping or grinding any paint or
debris between cooling fins.
2. Clean mounting area with a spray degreaser that will not leave a thin fil lubricating
residue.
3. Mix adhesive.
4. Apply adhesive to the sides and the bottom of the probe portion of the motor fin
mount probe/pad (the area is roughened to enhance the bonding area).
Installation
User Guide
August 2020 MHM-97927-PBF
46 MHM-97927-PBF, Rev 1
