b. Verify Show join key has a check mark.
Note
The most common cause of incorrect operation is that the Network ID or Join Key
are not set correctly in the device.
4.4 Device operating limits
Table 4-2: Standard, low-power sensor operational ranges
Sensor Range Frequency Response
Vibration Overall X 16g's 2.7 KHz
Vibration Overall Y 16g's 2.7 KHz
Vibration Overall Z 16g's 0.6KHz
PeakVue Z 80g's 20KHz
Temperature -40⁰C to 85⁰C N/A
4.5 Device variable alert limits
This table shows the alert limits of the device variables.
Table 4-3: Overall X
Axis Severity Upper Limit Lower limit Unit Remarks
Overall X Saturated 70 0 in/s
Overall X Sensor 70 0 in/s Overall X Out of Range
Overall X Range 5 0 in/s
Overall X Fail 1 NaN DV
Unused
in/s Overall X Out of Range
Overall X Maint 0.35 NaN DV
Unused
in/s Overall X Maintenance
Overall X Advise 0.14 NaN DV
Unused
in/s Overall X Advise
Table 4-4: Overall Y
Axis Severity Upper Limit Lower Limit Unit Remarks
Overall Y Saturated 70 0 in/s
Overall Y Sensor 70 0 in/s Overall Y Out
of Range
Overall Y Range 5 0 in/s
Overall Y Fail 1 0 in/s Overall Y
Failure
