Table 4-4: Overall Y (continued)
Axis Severity Upper Limit Lower Limit Unit Remarks
Overall Y Maint 0.35 0 in/s Overall Y
Maintenance
Overall Y Advise 0.14 0 in/s Overall Y
Advise
Table 4-5: Overall Z
Axis Severity Upper Limit Lower Limit Units Remarks
Overall Z Saturated 70 0 in/s
Overall Z Sensor 70 0 in/s Overall Z Out
of Range
Overall Z Range 5 0 in/s
Overall Z Fail 1 0 in/s Overall Z
Failure
Overall Z Maint 0.35 0 in/s Overall Z
Maintenance
Overall Z Advise 0.14 0 in/s Overall Z
Advise
Table 4-6: Peakvue Z
Axis Severity Upper Limit Lower Limit Units Remarks
PeakVue Z Error NaN NaN 250
PeakVue Z Unused NaN DV
Unused
NaN DV
Unused
250
PeakVue Z Saturated 100 0 g
PeakVue Z Sensor 100 0 g PeakVue Z Out
of Range
PeakVue Z Range 100 0 g
PeakVue Z Fail 40 0 g PeakVue Z
Failure
PeakVue Z Maint 20 0 g PeakVue Z
Maintenance
PeakVue Z Advise 10 0 g PeakVue Z
Advise
Table 4-7: Velocity Band 1
Axis Severity Upper Limit Lower Limit Units Remarks
Velocity Band
1
Unused NaN DV
Unused
NaN DV
Unused
250
