Emerson BUILDER Series User Manual

12
U.L. Model No.: 52-ANT
4. How to Hang Your Ceiling Fan (Continued)
To avoid possible fire or shock, do not pinch wires
between the hanger ball/downrod assembly and
hanger bracket.
WARNING
!
Failure to seat tab in groove could cause damage to
electrical wires and possible shock or fire hazard.
WARNING
!
OUTLET
BOX
HANGER
BRACKET
HANGER BALL/
DOWNROD
ASSEMBLY
NOTE: SUPPLY WIRES AND FAN WIRES OMITTED FOR CLARITY.
HANGER BRACKET
HANGER BALL
HANGER BALL
GROOVE
ANTI-ROTATION
TAB
Figure 15
4.2
Carefully lift the fan and seat the hanger ball/
d
ownrod assembly on the hanger bracket that was just
attached to the outlet box (Figure 15). Be sure the
groove in the ball is engaged with the anti-rotation tab
on the hanger bracket (Figure 15).
BP7312-4 CF700.qxp_ BP7312 2/27/15 5:14 PM Page 12
