Service Instructions
137462E Rev. D
August 2015
13
Section 3: Actuator Reassembly
Actuator Reassembly
NOTE:
Move the O-ring seal (7-30) down the ES or stop screw until it is next to
the housing adapter (6-10).
3.2.2.3 Install washer (6-90) onto ES or stop screw (6-30).
NOTE:
Push the washer down the ES or stop screw until it is next to the housing
adapter (6-10).
3.2.2.4 Install hex nut (6-40) onto ES or stop screw (6-30).
NOTE:
Rotate the hex nut down the ES or stop screw until it is next to the
housing adapter (6-10).
3.2.3 Apply a coating of lubricant to the torque shaft holes located on each side of
housing (1-10).
3.2.4 Coat rod wiper seal (2-20) with lubricant and install in the grooves located in the
upper torque shaft “through hole” of housing (1-10).
NOTE:
The cup of wiper seal will be installed facing down into the housing.
3.2.5 Coat u-cup seal (2-40) with lubricant and install into the groove located in the
lower torque shaft “through hole” of housing (1-10) - the inner most groove
nearest the yoke (1-20).
NOTE:
The cup of rod wiper seal will be installed facing into the housing.
3.2.6 Coat rod wiper (2-60) with lubricant and install into the outer most groove located
in the lower torque shaft “through hole” of housing (1-10).
NOTE:
The cup of rod wiper will be installed facing to the outside of housing (1-10).
3.2.7 Apply a generous amount of lubricant to the slots in the arms of yoke (1-20).
Coat yoke (1-20) with lubricant and install into housing (1-10).
3.2.8 Insert the yoke key (1-40) into the slot in the torque shaft (1-30).
