12. Repair Parts Listing
Before discarding packaging material, be certain all parts have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION:
• PART NUMBER • NAME OF ITEM
• PART DESCRIPTION • MODEL NUMBER
The model number of your Fan will be found on a label attached to the top housing.
For repair parts, phone 1-800-654-3545.
17
emersonfans.com
Please contact 1-800-654-3545 for further assistance
ETL Model No.: CF921
Key Model Numbers
No. Description CF921BS01 CF921GES01 CF921ORB01 CF921SW01 CF921VBN01
* Hanger Ball Assembly, 761655-17 761655-35 761655-32 761655-92 761655-89
Consisting of:
1 Hanger Bracket — — — — —
2 Hanger Ball — — — — —
3 Downrod (4.5”) — — — — —
* Parts Bag Containing: 764124-1 764124 764124 764124-1 764124
4 Wire Connector (3) — — — — —
5 Pin, Clevis (1) — — — — —
6 Clip, Hairpin (1) — — — — —
7 Threaded Stud, #8-32 x 1-1/4” (2) — — — — —
8 Lockwasher, External Tooth #8 (2) — — — — —
9 Knurled Knob, #8-32 (2) — — — — —
10 Screw, Washer Head,
#10-24 x 12mm (21) — — — — —
11 Flat Washer 16mm OD (21) — — — — —
12 Screw, Pan Head, 1/4-20 x 14mm with
Lockwasher (1) — — — — —
13 Screw, Flat Head, #8-32 x 8mm (1) — — — — —
14 Screw, Pan Head, #8-32 x 8mm (1) — — — — —
15 Balancing Kit (1) — — — — —
16 Canopy, Ceiling (1) 761620-BS 761620-GES 761620-ORB 761620-SW 761620-VNB
17 Motor Coupling Cover (1) 764118-BS 764118-GES 764118-ORB 764118-SW 764118-VNB
18 Switch Housing (1) 764116-BS 764116-GES 764116-ORB 764116-SW 764116-VNB
19 Flange Assembly (set of 5) 764134-BS 764134-GES 764134-ORB 764134-SW 764134-VNB
20 Motor Control, Receiver 764125-1 764125-1 764125-1 764125-1 764125-1
21 Control, Transmitter SR600 Remote SR600 SR600 SR600 SR600 SR600
—
Owner's Manual BP7433-3 BP7433-3 BP7433-3 BP7433-3 BP7433-3
