G-6 / Radio Ready Installation Guide CI-ControlWave EFM
Table 1 - Setup Menu Terminal Settings
PARAMETER SETTING
Baud Rate 19,200
Data Rate 8
Parity None
Stop Bits 1
Parity Check None/Off
Carrier Detect None/Off
Figure 4 - Cable Diagram for Radio to PC Interface
