Emerson Copeland EV2 Series - Drive Configuration Flow Charts

4 DRIVE CONFIGURATION FLOW CHARTS
Apply Power to Drive
Write Password “0x2345”
to Register 200.
Read Registers 201 to 213
(201 & 202 are
default,203 & 204 are
autoconfigured by the
drive)
Do values match
spec?
Faults?Query fault status
Write values according to
Modbus Map to Registers
205 to 213
Operate drive
Troubleshoot according to
the fault
YES
YES
NO
NO
