Dual-Compressor Module Introduction
1.2 The Compressor
The Compressor refers to the Copeland Scroll
®
Compressor. Each Compressor Module has two
Compressors. Figure 2 shows a cross-section of a Compressor and its key components.
Figure 2 Copeland Scroll
®
Compressor Cross Section
1.3 The Compressor Package
The Compressor Package consists of the Compressor Module housed in an assembly ready for service
in the eld. Equipment Packagers customize the assembly and complete the fabrication for Compressor
Modules for each application. Figure 3 shows a simplied example of a Compressor Package.
Figure 3 Typical Compressor Package
Oil
cooler
Gas aftercooler
(if applicable)
Control and
power panel
Compressor
Module
Inlet gas scrubber
for liquid removal
