11
Performance Table
Q=Capacity (kW) P=Power input (kW) 3-Phase
R22 60 Hz
Compressor
Condensing
Temperature
o
C
Evaporating Temperature (
o
C)
-12 -10 -5 0 5 10 12.5
ZBD48KQ
Q
15 13.85 14.60 16.85
19.55
20 14.45 15.40 17.95 21.00 24.60
30 14.05 15.15 18.15 21.60 25.60 30.10 32.60
40 12.55 13.65 16.70 20.10 24.00 28.50 31.00
50 11.30 12.30 14.90 18.00 21.50 25.40 27.70
55 12.10 14.40 17.15 20.20 23.80 25.80
60 14.35 16.55 19.25 22.30 24.10
65 16.60 18.65 21.20 22.60
P
15 3.69 3.88 4.39 4.96
20 3.64 3.77 4.10 4.47 4.92
30 4.20 4.25 4.38 4.50 4.65 4.85 4.97
40 5.19 5.24 5.35 5.41 5.47 5.52 5.55
50 6.04 6.18 6.46 6.66 6.81 6.91 6.96
55 6.46 6.90 7.24 7.51 7.71 7.79
60 7.17 7.70 8.13 8.48 8.63
65
7.97 8.62
9.16 9.40
Notes: Suction Return Temperature 18.3
o
C
Suction Superheat 11.0K
Liquid subcooling 0.0K
