Dimensional Data (mm):
PCN Description Series
Connection Size
(inch)
065391 HMI-1MM2
Male Flare x Male Flare
1/4
065392 HMI-1MM3 3/8
065393 HMI-1MM4 1/2
065394 HMI-1MM5 5/8
065395 HMI-1MM6 3/4
065405 HMI1-1TT2
Sweat x Sweat (ODF)
1/4
065406 HMI1-1TT3 3/8
065407 HMI1-1TT4 1/2
065408 HMI1-1TT5 5/8
065409
HMI1-1TT6
3/4
065410 HMI1-1TT7 7/8
065411 HMI1-1TT9 1 1/8
065396 HMI-1FM2
Female Flare x Male Flare
1/4
065397 HMI-1FM3 3/8
065398 HMI-1FM4 1/2
065622 HMI-1TT2MF
Sweat x Sweat (ODM x ODF)
1/4
065814 HMI-1TT3MF 3/8
065979 HMI-1TT4MF 1/2
065980 HMI-1TT5MF 5/8
Moisture Content Color Code (ppm H
2
O):
Indication Liquid
Temperature
Dry (Dark Blue) Caution (Purple) Wet (Salmon)
75°F 100°F 125°F 75°F 100°F 125°F 75°F 100°F
125°F
R-12 1.4 2.5 4 5 9 15 25 43 70
R-134A 20 35 60 35 55 85 130 160 190
R-22 25 35 50 40 65 90 145 205 290
R-407C 26 40 64 42 68 109 150 230 370
R-410A 30 55 75 50 85 120 165 290 420
R-404A/507 15 25 45 33 50 80 120 150 180
