Emerson Copeland Scroll - ZXLV Performance Data

10
© 2011 Emerson Climate Technologies
Printed in the U.S.A.
AE5-1377 R2
Application Engineering
BULLETIN
H.P.
Medium Temperature
Model Number
Btu/hr @ +25°F Sat. Suction
Temp / 90°F Ambient
Btu/hr @ +25°F Sat. Suction
Temp / 100°F Ambient
Refrigerant/
Oil Type
1.5 XJAM-015Z-CFV 14600 13600 R404A / POE
2 XJAM-020Z-CFV 19600 17900 R404A / POE
2 XJAM-020Z-TFC 19600 17900 R404A / POE
3 XJAM-030Z-CFV 28500 25900 R404A / POE
3 XJAM-030Z-TFC 28500 25900 R404A / POE
4 XJAM-040Z-CFV 38600 35300 R404A / POE
4 XJAM-040Z-TFC 38600 35300 R404A / POE
5 XJAM-050Z-CFV 47100 43800 R404A / POE
5 XJAM-050Z-TFC 47100 43800 R404A / POE
6 XJAM-060Z-TFC 54600 50200 R404A / POE
Table 1
Medium Temp Performance Criteria
H.P.
Low Temperature
Model Number
Btu/hr @ +25°F Sat. Suction
Temp / 90°F Ambient
Btu/hr @ -10°F Sat. Suction
Temp / 100°F Ambient
Refrigerant/
Oil Type
2 XJAL-020Z-CFV 13100 12700 R404A / POE
2 XJAL-020Z-TFC 13100 12700 R404A / POE
3 XJAL-030Z- TFC 17200 16400 R404A / POE
3 XJAL-035Z- CFV 19700 18100 R404A / POE
4 XJAL-040Z-CFV 24700 23700 R404A / POE
4 XJAL-040Z-TFC 24700 23700 R404A / POE
5 XJAL-050Z-CFV 27600 25700 R404A / POE
5 XJAL-050Z-TFC 27600 25700 R404A / POE
6 XJAL-060Z-TFC 34700 32700 R404A / POE
Table 2
Low Temp Performance Criteria
