Emerson CORESENSE User Manual

11
© 2018 Emerson Climate Technologies, Inc.
AEX-XXXX
PRELIMINARY
AE8-1384 R6
Table 4 - CoreSense Modbus Map Continued
Unused (18 bytes) - continued
381
Input and Output status
4
4
0x0001 - PTC Status (OK-1/Not OK-0)
0x0002 - Scroll High Temp NTC Status (OK-1/Not OK-0)
0x0004 - Spare Temp NTC Status (OK-1/Not OK-0)
0x0008 - L1 Voltage Status (Present-1/Absent-0)
0x0010 - L2 Voltage Status (Present-1/Absent-0)
0x0020 - L3 Voltage Status (Present-1/Absent-0)
0x0040 - Line Phase Voltage Status (OK-1/Not OK-0)
0x0080 - Line Reverse Voltage Status (OK-1/Not OK-0)
0x0100 - Pilot Voltage Status (OK-1/Not OK-0)
385
Scroll Temperature Value
2
2
(Scroll High Temp Sensor Value) Range = -0°C to
655.36°C
387
Spare Temperature Value
2
2
(Spare Temp Sensor Value) Range = -0°C to 655.36°C
389
Pilot Voltage Value
2
2
Pilot Voltage Value - Range 0 to 655.36 V
Unused (117 bytes)
400
Ten most recent alarms with time
stamp
40
60
428
Compressor run history with
cumulative count
11
20
433
Compressor start history with
cumulative count
19
20
446
Short Cycle history with cumulative
count
11
20
Unused (30 bytes)
46F
Seven day Warning history with
cumulative count
40
72
497
Seven day Trip history with cumulative
count
60
108
4D3
Seven day Lockout history with
cumulative count
70
126
