CROSBY J SERIES PRESSURE RELIEF VALVE WITH FISHER™ 4320 WIRELESS POSITION MONITOR
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
TABLE 2 LOCATION, BOLTING AND TORQUE
LOCATION DESCRIPTION BOLTING HARDWARE TORQUE (+/-5%)
1 Magnet to Stem Bracket M4 Cap Screws 20 in-lbs
2 Valve Monitor to Bracket M6-8-1 x 10 mm Cap Screws 50 in-lbs
3
Stem Jam Nuts 0.375-24 HEX JAM NUT 135 in-lbs
Stem Jam Nuts 0.500-20 HEX JAM NUT 160 in-lbs
Stem Jam Nuts 0.625-18 HEX JAM NUT 190 in-lbs
Stem Jam Nuts 0.750-16 HEX JAM NUT 250 in-lbs
Stem Jam Nuts 0.875-14 HEX JAM NUT 400 in-lbs
4
Mounting Bracket to Cap 0.437-14 BOLT 40 ft-lbs
Mounting Bracket to Cap 0.437-14 HEX NUT 45 ft-lbs
Mounting Bracket to Cap 0.500-13 HEX NUT 60 ft-lbs
Mounting Bracket to Cap 0.562-12 HEX NUT 90 ft-lbs
