CROSBY J SERIES PRESSURE RELIEF VALVE WITH FISHER™ 4320 WIRELESS POSITION MONITOR

INSTALLATION, OPERATION AND MAINTENANCE MANUAL

4 SELECTION TABLES

Depending on the size of the orifice and the pressure rating, the magnet the Bracket Kit will be selected.

Orifice Pressure Rating JBS-E Lift (Inch) JLT-JBS-E Lift (Inch) Magnet "A" Cap Group Bracket Kit PN Spindle Nut Thread

D 1-4() 0.121 0.151 7 mm 1 Group 1 11469009 0.375-24

D 5-7() 0.121 0.151 7 mm 1 Group 1 11469342 0.375-24

E 1-4() 0.165 0.205 7 mm 1 Group 1 11469009 0.375-24

E 5-7() 0.165 0.205 7 mm 1 Group 1 11469342 0.375-24

F 1-4() 0.207 0.257 7 mm 1 Group 1 11469009 0.375-24

F 5-6() 0.207 0.257 7 mm 1 Group 1 11469342 0.375-24

F 7() 0.207 0.257 7 mm 1.25 Group 2 11469343 0.500-20

G 1-4() 0.265 0.328 19 mm 0.875 Group 1 11469009 0.375-24

G 5-7() 0.265 0.328 19 mm 1.25 Group 2 11469343 0.500-20

H 1-3(),47 0.331 0.41 19 mm 0.875 Group 1 11469009 0.375-24

H 45,5-6() 0.331 0.41 19 mm 1.25 Group 2 11469343 0.500-20

J 1-2() 0.424 0.525 19 mm 0.875 Group 1 11469009 0.375-24

J 3-4(),57 0.424 0.525 19 mm 1.25 Group 2 11469343 0.500-20

J 55-6() 0.424 0.525 19 mm 1.25 Group 2 11469345 0.625-18

K 1-3(), 47 0.507 0.628 19 mm 1.25 Group 2 11469343 0.500-20

K 45, 57 0.507 0.628 19 mm 1.25 Group 2 11469345 0.625-18

K 55-6() 0.507 0.628 19 mm 1.38 Group 3 11469431 0.750-16

L 1-4() 0.631 0.782 25 mm 1.25 Group 2 11469345 0.625-18

L 5-6() 0.631 0.782 25 mm 1.38 Group 3 11469431 0.750-16

M 1-3() 0.709 0.878 25 mm 1.25 Group 2 11469345 0.625-18

M 4-5() 0.709 0.878 25 mm 1.38 Group 3 11469431 0.750-16

N 1-4() 0.0.779 0.964 25 mm 1.38 Group 3 11469431 0.750-16

P 1-3() 0.945 1.169 50 mm 1.38 Group 3 11469431 0.750-16

P 4-5() 0.945 1.169 50 mm 1.38 Group 3 11469433 0.875-14

Q 1-4() 1.243 1.539 50 mm 1.38 Group 3 11469433 0.875-14

R 1-4() 1.496 1.852 50 mm 1.38 Group 3 11469433 0.875-14

T 1-4() 1.907 2.361 110 mm 1.38 Group 3 11469433 0.875-14

T2 1-4() 1.974 N/A 110 mm 1.38 Group 3 11469433 0.875-14

TABLE 1 MAGNET AND BRACKET KIT SELECTION TABLE
