Emerson Dixell XC645CX User Manual

1592001440 XC645CX GB r3.4 31.10.2017.docx XC645CX 43/54
Mess.
Errata
Corrige
Too Many dGS
output
More than one oAi has
been set as dGs (digital
scroll)
• Check the oAi parameters and set
them different from dGS.
Too Many dGSt
output
One oAi has been set as
dGst (triac for digital
scroll)
• Check the oAi parameters and set
them different from dGSt.
Too Many 6dG
output
More than one oAi has
been set as 6dG (blocked
suction valve for digital
stream 6D)
• Check the oAi parameters and set
them different from 6dG.
6dG bEForE
dGS ConFig
Error
oAi configured as 6dG
before the dGS
• Check the oAi parameters and set
6dG after dGS.
dGSt OutPut
Error
One oAi has been set as
dGst (triac for digital
scroll)
• Check the oAi parameters and set
them different from dGSt.
dGSt not
PrESEnt
One oAi has been set as
dGs (digital scroll)
• Check the oAi parameters and set
them different from dGS.
dGS not
PrESEnt
One oAi has been set as
dGst (triac for digital
scroll)
• Check the oAi parameters and set
them different from dGSt.
StEP ConFiG
Error
Load (step) configuration
error
• A relay oA(i) has been set as
compressor without a previous relay
oA(i-1) has been set as compressor.
EI oA1 = StP
no P3 ProbE
PrESEnt
The P3 probe is
requested for a function,
but it’s not present
• Check the parameters P3C
no LoAdS For
rEGuLAtion
None oA(i) is set as
compressors or fans
• Check the setting of oA2, oA3, oA4,
oA6 parameters
AOP2
P2 probe not available for
the 4÷20mA output
• P2 probe not available P2P =no.
Enable the probe setting: P2P =yES
• The second probe P2 is used to
control the temperature of the engine
of screw compressors. Check CtyP
and set it different from Scr.
no FAn ProbE
P2 probe not available for
fan regulation
• P2 probe not available P2P =no.
Enable the probe setting: P2P =yES
• The second probe P2 is used to
control the temperature of the engine
of screw compressors. Check CtyP
and set it different from Scr.
too MAnY InC1
More than one oAi has
been set as inC1 (inverter
for suction 1)
• Check the oAi parameters and set only
1 as “inC1”.
No AnALoGuE
out For InC1
None analogue output
has been set as “inC1”
• Check AoF and 2AoF and set one of
them as “inC1”
too MAnY InF
More than one oAi has
been set as inF (inverter
for fan)
• Check the oAi parameters and set only
1 as “inF”.
No AnALoGuE
out For InF
None anlogue output has
been set as “inF”
• Check AoF and 2AoF and set one of
them as “inF”
