Emerson Dixell XC645CX User Manual

1592001440 XC645CX GB r3.4 31.10.2017.docx XC645CX 54/54
Label
Value
Menù
Description
Range
UAO
100
Pr2
Temperature value associated to the
maximum value of analog output, 10V or
20mA
-50.0÷150.0(°C) -58÷302(°F)
AOM
40
Pr2
Minimum value of analogue output
0 ÷ 100 (%)
AOt
5
Pr2
Time with analog output at max when after
exceeding AOM
0÷15s
MPM
100
Pr2
Maximum % variation per minute
nu, 1 ÷ 100%
SAO
80
Pr2
Percentage of analog output in case of probe
failure
0 ÷ 100 (%)
AOH
70
Pr2
Maximum analog output percentage when
silence mode function is enabled
0 ÷ 100 (%)
2AOC
Cur
Pr2
Analogue output2 working mode
Cur – tEn
2AOF
nu
Pr2
Analog output 2 function
nu - InC1 – InC2 – InF
2AOP
nP
Pr2
Reference probe for the analog output 2
nP(0) - P3(1) - P4(2)
2LAO
0
Pr2
Temperature value associated to minimum
value of analog output2 (2AOM)
-50.0÷150.0(°C) -58÷302(°F)
2UAO
100
Pr2
Temperature value associated to the
maximum value of analog output 2, 10V or
20mA
-50.0÷150.0(°C) -58÷302(°F)
2AOM
0
Pr2
Minimum value of analogue output2
0 ÷ 100 (%)
2AOt
0
Pr2
Time with analog output 2 at max when after
exceeding AOM
0÷15s
2MPM
100
Pr2
Maximum % variation per minute for analog
output 2
nu, 1 ÷ 100%
2SAO
50
Pr2
Percentage of analog output 2 in case of
probe failure
0 ÷ 100 (%)
2AOH
70
Pr2
Maximum analog output 2 percentage when
silence mode function is enabled
0 ÷ 100 (%)
tbA
YES
Pr1
Alarm relay silencing
no – yES
OAP
cL
Pr2
Polarity alarm relay
OP – CL
oFF
no
Pr2
off function enabled
no – yES
bUr
YES
Pr2
Buzzer enabled
no – yES
Adr
1
Pr2
Serial address
1 ÷ 247
rEL
3.4
Pr2
Release firmware
Readable only
Ptb
-
Pr2
Parameter table code
Readable only
Pr2
-
Pr1
Pr2 access
Readable only
